8MP Hd-Avs Indoor/Outdoor

8MP Hd-Avs Indoor/Outdoor

Store / Residential and Commercial Security
$299.99
In stock
Product Details

Finally, 4K resolution is available for surveillance cameras over Coax! The new AVS-4K series of cameras all produce stunning 4K video at 15FPS. The AVS-4KD8021-IR is an 8MP Day/Night bullet camera with a fixed 2.8mm lens, supporting 164' of intelligent IR illumination. Supporting both HD and SD output, this camera can be used for retrofit as well as green field installations. Typical applications for this type of camera include: businesses, interior/exterior residential applications, parking lots and gas stations. Like all HD-AVS cameras from IC Realtime, a compatible HD-AVS recorder is required to provide HD video transmission up to 2,296' over conventional Coaxial cable.


Note: For compatibility purposes, this camera may come default on 4MP/ 2MP resolution. When equipped with an appropriate HDVR, you can set the camera to the maximum resolution via the OSD interface.

Specifications

Camera
Image Sensor: 1/1.8" Starlight CMOS
Effective Pixels: 3840(H) x 2160(V)
Scanning System: Progressive
Minimum Illumination: 0.005Lux/F1.6 30IRE 0Lux IR on
S/N Ratio: More than 65dB
Illumination Distance: Up to 50m (164ft)
Illumination On/Off Control: Auto/ Manual
Illumination LEDs: 2
IR Wavelength: 850 nm
Camera Illumination Type: IR
Lens
Lens Type: Fixed lens / Fixed iris
Mount Type: Board-in
Focal Length: 2.8mm
Max. Aperture: F1.6
Angle of View: H: 110.8 degrees
Focus Control: N/A
Close Focus Distance: 1800mm (70.86')
DORI - Detect: 84m (276ft)
DORI - Observe: 34m (112ft)
DORI - Recognize: 17m (56ft)
DORI - Identify: 8m (26ft)
PTZ
Pan/Tilt Range: Pan: 0 ~ 360 / Tilt: 0 ~ 70 / Rotation: 0 ~ 360
OSD Menu: Multi-language
Video
Resolution: 8MP (3840 x 2160)
Frame Rate: 15fps@4K 20fps@6MP 25/30fps@4MP
Day/Night: Auto (ICR) / Manual
Backlight Compensation: BLC / HLC / WDR
White Balance: Auto / Manual
Gain Control: AGC
Noise Reduction: 2D / 3D
Smart IR: Auto / Manual
WDR: 120dB
Interface
Video Interface: 1-channel BNC high definition video output / CVBS video output (DIP switch)
Audio I/O: 1-channel audio in & Built-in Mic
Electrical
Power Supply: 12V DC +/- 30%
Power Consumption: Max 8W (12V DC IR on)
Environmental
Operating Conditions: -30C ~ +60C (-22F ~ +140F) / Less than 90% RH
Ingress Protection: IP67
Construction
Casing: Aluminium
Dimensions: 106mm x 99.2mm (4.17in x 3.9in)
Gross Weight: 0.62kg (1.37lb)
